Kubernetes (k8s) is a powerful tool for managing containerized applications, and it comes with a variety of features to manage storage efficiently. Two key components in this storage management are Persistent Volume (PV) and Persistent Volume Claim (PVC). Let’s break these down! 🚀

🏔️ What is a Persistent Volume (PV)?

  • Definition: A Persistent Volume (PV) is a piece of storage in the cluster that has been provisioned by an administrator or dynamically provisioned using Storage Classes.
  • Lifespan: Exists independently of any individual pod’s lifecycle, providing persistent storage.
  • Types of Storage: Can be backed by various storage systems like NFS, iSCSI, cloud providers, etc.
  • Management: Managed by the Kubernetes API, offering a uniform API for different storage types.

Key Features:

  • Persistent Storage: Ensures data is not lost even if the pod is destroyed.
  • Decoupled from Pods: Exists independently of the pods using it.
  • Reusability: Can be reused by different pods, maintaining the same data.

📑 What is a Persistent Volume Claim (PVC)?

  • Definition: A Persistent Volume Claim (PVC) is a request for storage by a user. It is similar to a pod requesting specific compute resources (CPU and memory).
  • Binding: When a PVC is created, Kubernetes looks for a PV that meets the request and binds them together.
  • Dynamic Provisioning: If no suitable PV is found, Kubernetes can create a new PV dynamically (if Storage Classes are configured).

Key Features:

  • Storage Requests: Users specify the size and access modes (ReadWriteOnce, ReadOnlyMany, ReadWriteMany).
  • Binding to PV: Automatically binds to a matching PV, or triggers dynamic provisioning.
  • Isolation: Ensures a user gets the storage requested and it is isolated from other users.

🎯 How PV and PVC Work Together

  • Request and Provision: Users create a PVC specifying their storage requirements.
  • Binding Process: Kubernetes finds a suitable PV and binds it to the PVC.
  • Access: The PVC can then be used by pods to mount the storage defined by the PV.

🛠️ Practical Example

  1. Define a Persistent Volume:
 apiVersion: v1
 kind: PersistentVolume
 metadata:
   name: my-pv
 spec:
   capacity:
     storage: 10Gi
   accessModes:
     - ReadWriteOnce
   hostPath:
     path: /mnt/data
  1. Create a Persistent Volume Claim:
apiVersion: v1
 kind: PersistentVolumeClaim
 metadata:
   name: my-pvc
 spec:
   accessModes:
     - ReadWriteOnce
   resources:
     requests:
       storage: 10Gi
  1. Use PVC in a Pod:
apiVersion: v1
 kind: Pod
 metadata:
   name: my-pod
 spec:
   containers:
   - name: my-container
     image: nginx
     volumeMounts:
     - mountPath: "/usr/share/nginx/html"
       name: my-storage
   volumes:
   - name: my-storage
     persistentVolumeClaim:
       claimName: my-pvc

🔑 Key Benefits

  • Persistence: Ensures data remains intact even if the pod is restarted or rescheduled.
  • Flexibility: Decouples storage from pod lifecycle, enabling better management.
  • Scalability: Supports dynamic provisioning, scaling storage needs on-demand.

Task: How to Add a Persistent Volume to a Node Todo App

  1. Create a Persistent Volume pv.yaml using a file on your node.
apiVersion: v1
 kind: PersistentVolume
 metadata:
   name: pv-todo-app
 spec:
   capacity:
     storage: 1Gi
   accessModes:
     - ReadWriteOnce
   persistentVolumeReclaimPolicy: Retain
   hostPath:
     path: "/tmp/data"

This manifest defines a PV resource named pv-todo-app with a capacity of 1 GB, an access mode of ReadWriteOnce (which means it can be mounted by only one pod at a time), a reclaim policy of Retain (which means it will not be deleted when unbound), and a hostPath type (which means it will use a directory on the host node as storage).

2. Create a Persistent Volume Claim pvc.yaml that references the Persistent Volume.

apiVersion: v1
 kind: PersistentVolumeClaim
 metadata:
   name: pvc-todo-app
 spec:
   accessModes:
     - ReadWriteOnce
   resources:
     requests:
       storage: 500Mi

This manifest defines a PVC resource named pvc-todo-app that requests 1 GB of storage, an access mode of ReadWriteOnce, no storage class, and a specific PV named pv-todo-app to bind to.

3. Update your deployment.yml file to include the Persistent Volume Claim. After Applying pv.yml pvc.yml your deployment file look like:

apiVersion: apps/v1
 kind: Deployment
 metadata:
   name: todo-app-deployment
 spec:
   replicas: 1
   selector:
     matchLabels:
       app: todo-app
   template:
     metadata:
       labels:
         app: todo-app
     spec:
       containers:
         - name: todo-app
           image: rishikeshops/todo-app
           ports:
             - containerPort: 8000
           volumeMounts:
             - name: todo-app-data
               mountPath: /app
       volumes:
         - name: todo-app-data
           persistentVolumeClaim:
             claimName: pvc-todo-app

This manifest defines a Deployment resource named todo-app-deployment that creates one pod with a container running the node-todo-app image. The container exposes port 8000 and mounts a volume named pv-todo-app at /app path. The volume uses the PVC named pvc-todo-app to claim the PV named pv-todo-app.

4. Create service.yaml

apiVersion: v1
 kind: Service
 metadata:
   name: todo-app-svc
 spec:
   selector:
     app: todo-app
   ports:
     - protocol: TCP
       port: 80
       targetPort: 8000
       nodePort: 30007
   type: NodePort

This manifest defines a Service resource named todo-app-svc that exposes port 80 and targets the pods with the label app:todo-app. This service allows us to access our app from outside the cluster.

5. Apply the manifests to create the resources on the K8s cluster:

 kubectl apply -f pv.yaml -f pvc.yaml -f deployment.yaml -f service.yaml

6. Verify that the resources are created:

 kubectl get pv,pvc,deploy,svc

You should see something like this:Congratulations!

You have successfully added a persistent volume to your Node Todo app.

    🚀 Conclusion

    Understanding PVs and PVCs is crucial for efficient storage management in Kubernetes. By leveraging these components, you can ensure your applications have reliable and persistent storage, making your deployments more robust and scalable. Happy Kubernetes-ing! 🥳🎉
